2027 Toyota Land Cruiser Off-Road Features and Terrain Modes

Which off-road systems come with each 2027 Land Cruiser grade?

The 2027 Land Cruiser comes in two grades. How the off-road gear splits between them is the most useful thing to know before you shop. Both grades run the same hardware underneath. The difference sits in the electronic systems layered on top.

Equipment availability above reflects Toyota’s official 2027 Land Cruiser product information.

Driver-assistance and advanced safety systems are supplemental aids and are not substitutes for safe and attentive driving. Availability, operation, and effectiveness vary by trim and equipment and depend on factors including road, weather, traffic, and vehicle condition. Always keep your hands on the wheel and your eyes on the road. See your owner’s manual for system limitations and details.

What terrain modes are included in the 2027 Toyota Land Cruiser Multi-Terrain Select system?

Multi-Terrain Select provides terrain-specific modes for Mud, Dirt, and Sand. It works in both 4WD High and 4WD Low ranges. Selecting a mode changes how the vehicle manages wheel slip, throttle response, and brake intervention for the surface under the tires.

How the modes change vehicle behavior

On loose surfaces like sand or deep mud, the system allows a controlled amount of wheelspin. That spin clears tread grooves and keeps the vehicle moving forward.

On harder, slicker surfaces, traction management tightens brake slip thresholds. This stops tires from spinning freely and redirects drive torque toward the wheels with the firmest grip.

Why the grade you choose matters here

Multi-Terrain Select is standard on the Land Cruiser grade. The 1958 does not offer it. For anyone who plans to drive off pavement regularly, this is one of the clearest dividing lines between the two grades.

What standard drivetrain hardware supports the 2027 Land Cruiser off road?

Standard off-road hardware on both 2027 Land Cruiser grades includes full-time four-wheel drive, an electronically controlled two-speed transfer case, and locking center and rear differentials. The turbocharged 2.4-liter i-FORCE MAX hybrid powertrain pairs with an eight-speed automatic transmission. Combined output is 326 net horsepower and 465 lb-ft of torque.

The full-time four-wheel-drive system sends power to both axles at all times, on pavement and off. When you need more torque, shift the transfer case into 4WD Low. That engages a low-range gear for slow climbs and controlled descents.

How the locking differentials work

• Center locking differential: binds the front and rear axles together, so one axle losing grip doesn’t rob the other.
• Rear locking differential: binds both rear axle shafts, forcing both rear wheels to turn at the same speed regardless of surface resistance.

Vehicle Stability Control and an automatic limited-slip differential (Auto LSD) back both systems up on every 2027 Land Cruiser.

Powertrain and capability figures

Maximum towing and payload capacity figures are based on properly equipped vehicles and vary by configuration. Do not exceed any weight rating. See your owner’s manual and the vehicle’s door-jamb label for specific capacities.

You can compare both grades in person — see the 2027 Land Cruiser models at Capistrano Valley Toyota.

How do CRAWL Control and the Stabilizer Disconnect Mechanism work on the trail?

CRAWL Control

CRAWL Control is a low-speed off-road cruise control with five selectable speeds. It is standard on both grades. With CRAWL engaged, the system handles throttle and braking for you. You steer. Downhill Assist Control works alongside it, holding a steady speed on steep descents.

Stabilizer Disconnect Mechanism

The Stabilizer Disconnect Mechanism is available on the Land Cruiser grade. On pavement, the front stabilizer bar limits body roll through corners. Off pavement, pressing the console button disconnects that bar and lets the front suspension move through more of its travel.

The added articulation keeps the front tires pressed against uneven ground. That means better grip on off-camber sections and stepped obstacles.

Driver-assistance and advanced safety systems are supplemental aids and are not substitutes for safe and attentive driving. Availability, operation, and effectiveness vary by trim and equipment and depend on factors including road, weather, traffic, and vehicle condition. Always keep your hands on the wheel and your eyes on the road. See your owner’s manual for system limitations and details.

How does the Multi-Terrain Monitor work on the 2027 Toyota Land Cruiser?

The Multi-Terrain Monitor is part of Toyota’s Panoramic View Monitor system and comes standard on the Land Cruiser grade. It uses several cameras to show the area around the vehicle on the touchscreen. That helps you spot obstacles you cannot see from the driver’s seat. Think of the rocks, ruts, and stumps that vanish under the hood as the truck noses over a crest.

Those camera views appear on the Land Cruiser grade’s 12.3-inch touchscreen. The Land Cruiser 1958 runs an 8-inch touchscreen and does not include the Multi-Terrain Monitor.

Driver-assistance and advanced safety systems are supplemental aids and are not substitutes for safe and attentive driving. Availability, operation, and effectiveness vary by trim and equipment and depend on factors including road, weather, traffic, and vehicle condition. Always keep your hands on the wheel and your eyes on the road. See your owner’s manual for system limitations and details.

What are the towing, angle, and underbody protection specs for the 2027 Land Cruiser?

The 2027 Land Cruiser carries a maximum towing capacity of 6,000 pounds and a 22-degree departure angle. It rides on Toyota’s TNGA-F platform — the same high-strength boxed frame architecture underneath the Tundra, Sequoia, Tacoma, and 4Runner.

Departure angle is the steepest grade the rear bumper can drop away from without dragging. On a stepped descent, it is the figure that limits a Land Cruiser first.

Maximum towing and payload capacity figures are based on properly equipped vehicles and vary by configuration. Do not exceed any weight rating. See your owner’s manual and the vehicle’s door-jamb label for specific capacities.

Underbody protection and recovery points

• Skid plate coverage for the engine, transmission, and transfer case
• Front and rear tow hooks for recovery gear
• Standard trailer hitch with trailer wiring harness

New for 2027: the available High Mounted Air Intake

The one genuinely new piece of off-road hardware for the 2027 model year is an available High Mounted Air Intake. Toyota offers it on both the Land Cruiser 1958 and the Land Cruiser grade. It moves the engine’s intake point higher up, where dust and spray are thinner.

One thing to know before you order it: this is a raised intake, not a sealed snorkel. It is not designed to be watertight, and Toyota does not publish a water fording depth for the Land Cruiser.

Quick Answers to Common 2027 Toyota Land Cruiser Off-Road Questions

Does the 2027 Land Cruiser offer a rear locking differential as standard equipment?

Yes. Both 2027 Land Cruiser grades come standard with locking center and rear differentials. The rear locking differential binds both rear axle shafts together so the rear wheels turn at the same speed when traction is uneven.

Can Multi-Terrain Select be used in both 4WD High and 4WD Low?

Yes. Multi-Terrain Select is operable in both 4WD High and 4WD Low, with terrain-specific modes for Mud, Dirt, and Sand. It is standard on the Land Cruiser grade and is not offered on the Land Cruiser 1958.

What warranty coverage comes with the 2027 Toyota Land Cruiser powertrain and hybrid battery?

Toyota covers the 2027 Land Cruiser with a 36-month/36,000-mile basic warranty and 60-month/60,000-mile powertrain coverage. Hybrid components are covered for 8 years/100,000 miles, and the hybrid battery for 10 years/150,000 miles.

Coverage terms are published in Toyota’s 2027 Land Cruiser warranty summary.

This information is provided for general educational purposes only and does not constitute legal advice. Warranty coverage depends on the specific terms of your vehicle’s warranty agreement. Consult your owner’s manual or a qualified legal professional for guidance on your individual situation.

Test Drive the 2027 Toyota Land Cruiser in San Juan Capistrano

Our team at Capistrano Valley Toyota can show you how the locking differentials engage. We can walk you through the camera views on the touchscreen. We can also explain which off-road systems come with each grade. That last part matters most if you plan to use them.

Visit our showroom at 33395 Camino Capistrano in San Juan Capistrano, or call (949) 779-5480 to set up a walkaround. We also serve drivers in Dana Point, San Clemente, Capistrano Beach, Laguna Niguel, Ladera Ranch, and Mission Viejo. If you’re still weighing options, our full new Toyota inventory covers the rest of the lineup.
